GVS9000 1U AMD



GVS9000 1U AMD Render Node

The GVS9000 1U AMD delivers the latest in dual 64-bit processor performance in a 1U rackmount server. Using the power of dual AMD Opteron™ processors, the GVS9000 1U AMD provides high memory bandwidth with low latency, cutting edge 64-bit processing capabilities, and incredible I/O bandwidth defined by the 64-bit computing architecture and HyperTransport™ technology. With the support of two to four hot-swap Serial ATA or U320 SCSI RAID drive bays, dual gigabit Ethernet ports and a single 10/100 Ethernet port, the GVS9000 1U AMD provides the best features and performance for the latest in render farm, CAD, 3DFX, graphics, video, departmental and network infrastructure applications.

GVS9000 1U AMD OPTERON

Processor
 • Dual PGA 940-pin ZIF sockets
 • Supports up to two AMD Opteron™ processors

Chipset
 • AMD-8131™ HyperTransport™ PCI-X Tunnel
 • AMD-8111™ HyperTransport™ I/O Hub
 • Winbond™ W83627HF Super I/O ASIC
 • Analog Devices ADM1027 Hardware Monitoring IC

Memory
 • 128-bit dual channel memory bus
 • (8) 184-pin 2.5-Volt DDR DIMM sockets
 • Supports up to 16GB of Reg. DDR memory
 • Supports ECC type memory modules
 • Supports DDR 400/333/266/200 memory

Expansion Slot
 • (1) 64-bit/133MHz (3.3V) PCI-X slot on riser card

Integrated LAN Controllers
 • (2) GbE ports (Broadcom BCM5704C dual-channel
    GbE LAN controller connected to PCI-X bridge),
    with teaming feature support
 • (1) 10/100 Fast Ethernet port (Intel 82551QM)

BIOS
 • AMI BIOS 8.0 on 4Mbit LPC Flash ROM
 • Supports ACPI 1.0b & 2.0
 • PnP, DMI2.0, WfM2.0 Power management
 • Power Management S1, S4, and S5 support

Back I/O Ports
 • Stacked PS/2 Mouse & Keyboard ports
 • Stacked 2 USB 1.1 ports
 • (1) 9-pin UART Serial port; (1) 15-pin VGA port
 • (3) RJ45 connections

Integrated PCI Graphics
 • ATI® RAGE™ XL 8MB PCI graphics controller

Chassis: Metal

Chassis Form Factor
 • Industry 19" rack-mountable 1U chassis
 • Dimension (inch): 17" (W) x 26.5" (D) x 1.7" (H)
 • Dimension (mm): 432 (W) x 673 (D) x 43 (H)

 Drive Bays - 2 external 3.5" HDD bays

Storage
 • Hard Disk Drives - support 2 to 4 hot-swappable
    SATA HDD with RAID 0, 1, 10
• Optional SCSI Disk Drives - support 4 hot-swappable
    Adaptec dual channel U320 with RAID
 • One slim CD-ROM drive (standard)
 • One 3.5" bay for FDD or internal HDD

Power Supply - EPS 12V 400W output w/ PFC

Front Access I/O ports
 • I/O - two USB 1.1 ports
 • LED indicators
     - (2) HDD LEDs
     - (1) IDE channel activity LED
     - (3) LAN link/activity LEDs
     - Power LED; Fan LED
 • Switch - power; reset; buzzer

Server Management
 • Optional SMDC (remote server
    management kit), IPMI 1.5 compliant
 • System fan speed control

Regulatory
 • FCC Class B (Declaration of Conformity)
 • CE (Declaration of Conformity)
 • UL (Underwriters Laboratories Inc.) certified





G1U08131260-2


GVS9000 1U Rack Mount Chassis:

:


Processor:


Nomadic Drive:


Memory ECC Register:


Graphics Cards :


Optical Drive:


Interface Card:


Floppy Drive :


Rack Railling:


Power Supply:


Operating System:


GVS Warrantee Service Plan:
