Grande Vitesse Systems nomadic 1U 12xPro SSS

gvs9000 vtr storage workstations asset management


Nomadic 1U 12xPro SAN storage

Nomadic 1U 12xPro 1-12TB storage in areal density of 3,600 Gb/inē

Applications design for extremely quote, rugged, high performs,1-12TB and 12 hot-swap drives high-performance 10Gbit iSCSI or 8GB fiber (2x4Gb/s) channel hardware RAID controller on desktop space with Operating Systems support and tested BSD, Linux, Unix, NetWare, Win's, AIX, VMWare, Solaris and OS X

Supported Capacities Start from:
1TB - 12TB

Available Options include:
• single or dual hardware RAID 4480C/4480i controllers redundant
• Drive capacities 300Gbit 600GB or 1000GB SATA-II 7200RPM. Secure drive technology with high G-Force or 15,000RPM 146GB, 300GB or 10,000RPM 600GB, 900GB and SOLID STATE DRIVE SSD SLC or MLC Drive.
• Dual iSCSI 10Gbit or 4x8Gb Fibre host interface
• 1-2 124 port SATA-II expansion port (up to 750TB)

• iSCSI Independent host interface option
• Hardware and Software management with TCP/IP and RS232 ports
• RAID 0, 1 ,3 ,5 , 6, 50, 51, 60, 61, 1+0, & 0+1
• 18 SATA-II hot-swap drive bays
• 24 drive bay SAS Expansion interface

• Dual Battery backup for cache memory
• Design with very quite cooling noise
• Desktop or rack install kit included
• Full populated weight less than 20lb
• highly ruggedisze drive system for mobile environment
• LED drive states and accesses options.
• Dual 275W hot-swap Power supply
• Three removable cooling system





GVS Storage
The Nomadic 1U 18xPro array provides a compact and affordable, storage solution that's simple to deploy and easy to manage. Designed to support growing storage requirements, the high-density array scales to meet your business needs, and its building-block approach reduces costs and simplifies future upgrades to enterprise SAN or NAS solution.

Nomadic4U Expandable to 128 drive bay per SAS port

Finally a product that doesn't require a refrigeration to keep it cool, with complete environment factor of low power, noise and light material, it ideal design to be keep on desk side or studio, the Nomadic 1U 18xPro. with the 4480c Controller Technology which offer the SAS expansion port option your able to expand the storage requirement to a enterprise level to 250 drive bay so you can buy the storage capacity you need today and be able to quickly and non-disruptively add mixed drive capacity as you grow. The built-in controllers browser-based management tool simplifies the management of your SAN and is an ideal way to expand your storage needs. With dual 8Gb/s connectivity up to Dual 8Gb/s total, exceptional data availability, reliability, and the flexibility you need as your storage grows from 13.5TB to 18TB in single 1U rack space, the Nomadic 1U 18xPro offers an elite storage solution at an entry-level price.
The array is easy to deploy, with flexible configuration and management options, online capacity expansion, and remote monitoring. A single GUI network interface provides common storage management across all arrays in the Nomadic 1U 18xPro Family, reducing the number of elements you need to manage.
In data intensive environments, increasing the capacity per disc drive lowers ownership costs by deploying fewer systems that use less cubic feet of space requiring less infrastructure such as cabinets, HBAs, and less wattage of power. The Nomadic 1U 18xPro uses 7.2K RPM high-performance 2.5" drive capacity with SATAII drive bay. Users who have the need for extreme speed to reach over 5.8Gbit/sec for RAW 2K, 4K film resolutions, or 1080p 60 frame, virtually eliminating the need for costly SAN solution for enterprise level product support.
Part Number
Model Number
Hardware Raid
Max. Drive Cache
Controller Cache
Host Interface
Drive Bay
SAS Expansion Ports
Max. Storage
Power Supply
N01U18ATP2F021
Nomadic1U-18F1
1x3890C
192MB
512MB
2x4Gb/s
18
1xSASe
12.0TB
2
N01U18S2P2I023
Nomadic1U-18I2
1x3890I
256MB
1GB
2xiSCSI
18
1xSASe
12.0TB
2
N01U18ATP2F044
Nomadic1U-18F4
2x4480
288MB
1GB
2x4Gb/s
18
2xSASe
13.5TB
2
N01U18S2P2F023
Nomadic1U-18E1
4480e
288MB
512MB
SAS Expansion
18
2xSASe
13.5TB
2





N1U12iSCSI15KRPM
